OpenPrinting Printers Printrex. Printrex.: User-contributed printer entry which is not yet verified and/or proofread.The printer entry is not included in the Foomatic packages yet. What driver settings should I use? In order for the Printrex 920 printer to find the black form marker on the fanfold paper (which is located near the paper perforation), so that the print jobs start printing at the paper perforation, be sure to select “Form Feed” for the “Start-of-job-Control” in the Properties of the 920 driver.

Download the Printrex 800 Series spec sheet PDF

Order by calling
1-877-748-4222 today!

The Printrex 800 series are the ideal thermal plotters for well logging, seismic, side scan sonar and mapping. Hand built to order in the United States; these printers embody a sleek design with rugged reliability that can withstand the harshest land, sea and air environments.
The 800 series consists of four high resolution, grey scale plotters with user defined configurability. These printers are unmatched in the industry and offer high throughput, efficient handling with field proven architecture and superior quality.
Highlights:
• 8 inch print widths
• 2 inches per second and 4 inches per second plot speed
• 200 dots per inch and 300 dots per inch print density
• Desktop, Rack-Mount and Panel-Mount Models
• USB and Ethernet connectivity capabilities
• Top of Form (TOF) sensor

Rugged Reliability
Designed specifically to handle the environmental challenges of logging trucks and off-shore platforms while maintaining data integrity from file to output.
Gray Scale Printing
All models in this product family can print 32 levels of gray. This is indicated by the “G’ in the suffix to the model number.
Ease of Use and Efficiency
With an average weight of 20 lbs, the 800 series printers are lightweight, compact printers with convenient access to internal parts. The simplicity of design and interface allows for little user intervention and keeps printer in full production.
Media Specifications
As a thermal printer, the only consumable necessary is paper. Paper and film are both compatible.

Printer Selection Guide

Model	Plot Speed		Dot Density		Line Length			Spec Sheet
Inches/Sec	mm/Sec	Dots/Inch	Dots/mm	Inches	mm	Dots/Line	Download
822 G	2	50	203	8	8.5	216	1,728	822 G Spec Sheet
822 DL/G	2	50	203	8	8.5	216	1,728	822 DL/G Spec Sheet
843 DL/G	4	100	300	11.81	8.5	216	2,560	843 DL/G Spec Sheet

Physical Characteristics

Dimensions H x W x D		Shipping Weight
Inches	Centimeters	Pounds	Kilograms
8-inch width printers
- Panel Mount	4.1 x 11.9 x 4.97	10.4 x 30.2 x 12.6	7	3.2
- Desk Top	4.87 x 12.3 x 12.0	12.4 x 31.2 x 30.5	21	9.5
- Rack Mount	5.25 x 19 x 16 12	13.3 x 48.3 x 41	22	10

Printrex 820 DL

Black & White printer, max. 200x200 dpi, works Partially

Printrex 840 Dl/g Driver

Discussion forum

Look for help in our forum for printers from various manufacturers.

Miscellaneous

Printer supports direct text printing with the 'us-ascii' charset.

Comments

Data logging printer; prints on continuous roll thermal paper.

Prints text just fine, and the command set is fully documented.

It should be straightforward to write a Ghostscript driver for the two bitmap modes (100 and 200dpi).

Consumables/Refills: Just thermal paper
